| Business Type | Supplier, Trader |
| CPU | Quad-core 1.3 GHz, 64-bit ARM Cortex-A35 |
| Memory | 512 MB DDR3 RAM |
| Flash | 8 GB eMMC |
| Click to view more | |
Product Details
Extendable Storage
1 × Micro SD Slot (Internal)
Antenna Connector
1 × 50 Ω SMA Connector (Center PIN: SMA Female)
Channel
8 (Half-duplex)
Frequency Band
CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4
Sensitivity
140 dBm Sensitivity @292bps
Output Power
27 dBm Max
Protocol
V1.0 Class A/class B/class C and V1.0.2 Class A/class B/class C
LBT
Support
Port
1 × RJ45 (PoE PD supported)
Physical Layer
10/100 Base-T (IEEE 802.3)
Data Rate
10/100 Mbps (Auto-Sensing)
KL56 is a robust 8-channel indoor LoRaWAN gateway. Adopting SX1302 chip and high-performance quad-core CPU, KL56 supports connection with more than 2000 nodes. KL56 has line of sight up to 15 km and can cover about 2 km in urbanized environment, which is ideally suited to smart building, smart industries and many other indoor applications.
KL56 supports not only multiple back-haul backups with Ethernet, Wi-Fi and cellular, but also has integrated mainstream network servers (such as TTI, ChirpStack, etc.) and built-in network server and Kled measurement IoT Cloud for easy deployment.
